Energy-efficient contact heating plate with a power rating of 13 watts, suitable for naturally rearing approximately 15 chicks. Featuring convenient height adjustment, a robust ABS plastic housing and a 25 × 25 cm heating surface. Available with or without a power dimmer.
This contact heating plate provides newly hatched chicks with a sheltered, comfortably warm resting area. It works according to the natural principle of a mother hen: when chicks need warmth, they gather underneath the plate and warm themselves through direct contact with its heated underside.
Measuring 25 × 25 cm and consuming a maximum of just 13 watts, the heating plate is an extremely energy-efficient alternative to conventional infrared heat lamps. It is suitable for rearing approximately 15 chicks, depending on their size and age.
Natural Contact Heat Instead of Heating the Entire Area
The underside of the heating plate reaches a temperature of approximately 50 °C. Heat is primarily transferred to the chicks through direct contact.
Important: The heating plate must be positioned low enough for the chicks to touch its underside with their backs. Unlike radiant heating plates or heat lamps, this model provides very little heating to the surrounding air or the floor beneath it.
The chicks can move freely between the warm area underneath the plate and the cooler parts of their rearing environment.
Convenient Height Adjustment
The four height-adjustable legs can easily be adapted to the size of the chicks. This allows the heating plate to be raised as the chicks grow during their first weeks of life.
The sturdy housing is made from temperature-resistant ABS plastic. Its construction is designed to provide reliable warmth and withstand regular use during chick rearing.
Available With or Without Power Dimmer
The contact heating plate is available in two versions:
-
Without power dimmer: The heating plate operates at its normal heating power. The warmth received by the chicks can be influenced by adjusting the height.
-
With power dimmer: In addition to height adjustment, the electrical heating power can be adjusted using a multi-level dimmer according to the chicks' requirements.
As the chicks grow older and require less warmth, the heating power can be reduced accordingly.
Product Features
-
Contact heating plate for approximately 15 chicks
-
Natural heating principle inspired by a mother hen
-
Extremely low power consumption of up to 13 watts
-
Direct heat transfer through the underside
-
Underside temperature of approximately 50 °C
-
Four conveniently height-adjustable legs
-
Robust, temperature-resistant ABS plastic housing
-
No additional visible light emission
-
Suitable for rearing chicks of various poultry species
-
Available with or without a multi-level power dimmer
Technical Specifications
-
Product type: Contact heating plate for chick rearing
-
Dimensions: 25 × 25 cm
-
Power consumption: max. 13 watts
-
Operating voltage: 220–240 V
-
Material: ABS plastic
-
Underside temperature: approx. 50 °C
-
Capacity: approx. 15 chicks, depending on size and age
-
Height adjustment: Four adjustable legs
-
Power control: Optional multi-level power dimmer
Scope of Delivery
-
1 contact heating plate, 25 × 25 cm, 13 watts
-
4 height-adjustable legs
-
Power cable with mains plug
-
1 additional power dimmer if the corresponding version is selected
Instructions for Use
Place the heating plate on a level, stable surface in the rearing area. Adjust the height so that the chicks can touch the heated underside with their backs without being confined.
Regularly observe the chicks' behaviour and adjust the height and, if applicable, the heating power according to their warmth requirements. Chicks must always be able to leave the area underneath the plate freely.
The contact heating plate does not replace an adequate ambient temperature in an excessively cold rearing room. It is designed to provide targeted warmth through direct contact.
Protect electrical components from moisture and damage. Disconnect the power supply and allow the heating plate to cool before cleaning. Follow the operating and safety instructions.
